Machine size: 2.2 mtrs long Vacuum Conveyor.
(nylon)
Vacuum system : 300 CFM Turbine Blower for Card holding on
conveyor
Speed (with inkjet printing inspection) : 18,000 cards/hour
Motor : AC motor – BONFIGLOI
A.C. Drive :Siemens or Allen Bradley
Cards feeding speed : 250 / min. Vacuum Feeding Unit (500 mm
long)>
Material of Construction : Complete S.S.
Card sizes : Card samples to be provided by the customer
Stacker/Destacker Magazine: for Horizontal movement
Brackets for sensors : Inkjet sensor + Label applicator sensors
Rejecter unit: PLC controlled pneumatic Operated rejection
Collector unit : collector bin will be provided
Label Applicator system with accuracy of ±1.0 mm
(Depending on card and label quality)
Machine Specifications
PRINTING OPTIONS (Single Up, Four Up &
Five Ups)
Machine speed: 18,000 cards/hour
Motor: Servo Motor (imported) with display & controlling unit.
Cards feeding speed : 300 cards per min. (Plastic & Paper 200
gsm)
Material of Construction: S S & Aluminium
Card sizes: Card samples to be provided by the customer (plastic
or paper)
